VK 11 Vikay Paving Breaker
Description
VK 11 Vikay Paving Breaker
Vikay is a Global Supplier of Pneumatic Paving Breaker Model VK 11 from India

Paving Breaker also known as Concrete Breaker is a high productivity tool, suitable for Demolition of Concrete, digging of asphalt, rock outcrop & digging of hard clay and laterite trenching work
This Paving Breaker is made from Top Quality Raw Material. The Valves, Pistons and other moving parts are made from Shock resistant Tool Steels, Heat treated to a specific rockwell hardness of toughness and durability. The Handle, Front Heads, Back Heads, and Cylinders are made from Carbonizing of Drop-Forged exceptionally Hard Alloy Steel.
Features
- Drop Forged Alloy Steel Body Parts
- Built In Automatic Oiler
- Spring Type Retainers
- Swivel Hose Connection
- Reversible Piston
- Rubber Handle Grips
- Heavy Duty Front Head Spring
Optional : Noise Dampening Muffler available
Technical Details
| Model | VK-11 | Â |
| Weight | 38 Kgs | 84 lbs |
| Overall Length | 710 mm | 27" |
| Air Consumption | 42 l/s | 88 cfm |
| Piston Diameter | 57.15 mm | 2 1/4" |
| Piston Stroke | 165 mm | 6 1/2" |
| Shank Size | 31.7 x 152.4 mm    | 1 1/4" x 6"  |
| Hose Size | 19 mm | 3/4" |
| Blows per Minute | 1200 bpm | Â |
 Since approvement are made from time to time, the illustration and specifications are subject to change without notice.
